Key Specifications
Engine
Four stroke, 50° V twin SOHC, 4 valves per cylinder, self-adjusting cam chains, hydraulic lifters
Torque
144 Nm / 14.6 kgf-m / 106 ft-lb
Fuel Capacity
22 Litres / 5.8 US gal
Advertisement
Full 2013 Victory Hard-Ball Specifications
Year
2012 - 13
Make Model
Victory Hard-Ball
Seat Height
667 mm / 26.2 in
Wheelbase
1647 mm / 64.8 in
Ground Clearance
120 mm / 4.7 in
Length
2372 mm / 93.4 in
Dry Weight
340 kg / 751 lbs
Fuel Capacity
22 Litres / 5.8 US gal
Maximum Load / GVWR
1151 lbs / 523 kg
Oil Capacity
4.73 L / 5.0 US Quarts
Displacement
1731cc /106 cu-in
Engine Detail
Four stroke, 50° V twin SOHC, 4 valves per cylinder, self-adjusting cam chains, hydraulic lifters
Bore x Stroke
101 x 108 mm
Compression Ratio
9.4:1
Cooling System
Air/oil cooled
Exhaust
Split dual exhaust with crossover
Fuel Induction
Electronic Fuel Injection with dual 45mm throttle bodies
Starter
-Electric
Battery Capacity
12V, 18 Ah
Clutch
Wet, multi-plate
Final Drive
Carbon fiber reinforced belt
Transmission / Drive
6 Speed
Suspension - Front
43mm Conventional telescopic fork
Suspension - Rear
Single, mono-tube gas Cast Aluminum with rising rate linkage, Preload adjustable spring
Rake
32°
Trail
170 mm / 6.7 in
Wheel Travel - Front
130 mm / 5.1 in
Wheel Travel - Rear
75 mm / 3.0 in
Brakes - Front
2x 300mm floating rotor 4 piston caliper, ABS
Brakes - Rear
Single 300mm floating rotor 2 piston caliper, ABS
Tyres - Front
130/70-18 67H Dunlop 491 Elite II
Tyres - Rear
180/70-16 Dunlop Elite 3
