Key Specifications
Torque
60.00 Nm (6.1 kgf-m or 44.3 ft.lbs) @ 4750
Weight
218.0 kg / 480.6 lbs
Fuel Capacity
14.10 litres / 3.73 gallons
Advertisement
Full 2012 Honda NC700X Specifications
Comments
Model ID: TRX680FA
Colours
Red/black, black, silver/black, black/white
Warranty
One year. Unlimited milage. Transferable.
Ground Clearance (mm)
165 mm
Ground Clearance (in.)
6.5 inches
Seat Height
830 mm / 32.7 in.
Wheelbase
1,540 mm / 60.6 in.
Height
1,285 mm / 50.6 in.
Length
2,210 mm / 87.0 in.
Width
830 mm / 32.7 in.
Fuel Capacity
14.10 litres / 3.73 gallons
Wet Weight
218.0 kg / 480.6 lbs
Bore x Stroke (in,)
1.4 x 2.9 inches
Bore x Stroke (mm)
36.0 x 73.0 mm
Displacement (cc)
670.00 cc
Displacement (ci)
40.88 cubic inches
Engine Type
Twin, four-stroke
Fuel Control
Overhead Valves (OHV)
Fuel System
Injection
Compression Ratio
10.7:1
Emissions
Meets current California Air Resources Board (CARB) off-road emissions standards.
Engine Lubrication
Dry sump
Fuel Reserve
4.54 litres / 1.20 gallons
Ignition
Computer-controlled digital transistorised with electronic advance
Starter
Electric
Clutch
Manual (DCT version = D mode/S mode/Manual mode)
Final Drive
Chain
Gearbox
3-speed
Primary Drive
Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential
Suspension - Front
41mm telescopic fork, 153.5mm travel
Suspension - Rear
Monoshock damper, Pro-Link swingarm, 150mm travel
Wheel Travel - Front
175 mm / 6.9 in.
Wheel Travel - Rear
203 mm / 8.0 in.
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Rear Diameter (in.)
9.4 inches
Brakes - Rear Diameter (mm)
240 mm
Brakes - Front
Single disc
Brakes - Rear
Single disc
Rims
Multi-spoke cast aluminium
Tyres - Front
120/70-ZR17
Tyres - Rear
160/60-ZR17
