Key Specifications
Engine
In-line three, four-stroke
Torque
87.0 Nm (8.9 kgf-m or 64.2 ft.lbs) @ 7250 Revolutions"
Top Speed
196.0 km/h / 121.8 mph
Weight
198 kg / 436.5 lbs
Fuel Capacity
20.00 litres / 5.28 US gallons
Advertisement
Full 2023 Triumph Tiger 900 GT Pro Specifications
Comments
5 riding modes. Electronic RSU. Heated seats.
Colours
Pure White, Sapphire Black, Caspian Blue
Seat Heigth -Alternate (mm)
840 mm
Seat Heigth -Alternate (in.)
33.1 inches
Seat Height
820 mm / 32.3 in.
Wheelbase
1556 mm / 61.3 in.
Height
1460 mm / 57.5 in.
Width
930 mm / 36.6 in.
Dry Weight
198 kg / 436.5 lbs
Fuel Capacity
20.00 litres / 5.28 US gallons
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
In-line three, four-stroke
Displacement (ci)
54.19 cubic inches
Displacement (cc)
888.0 cc
CO2
120.6 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
78.0 x 61.9 mm
Bore x Stroke (in,)
3.1 x 2.4 inches
Fuel System
Injection. Multi-point sequential electronic fuel injection
Compression Ratio
11.3:1
Emissions
Euro 5
Engine Lubrication
Wet sump
Exhaust
Stainless steel 3 into 1 header system, side mounted stainless steel silencer
Fuel Consumption
5.20 litres/100 km (19.2 km/l or 45.23 mpg)
Starter
Electric
Valve System
4
Clutch
Wet multi-plate
Final Drive
Chain (final drive)
Gearbox
6-speed
Primary Drive
O-ring chain
Frame Type
Tubular steel, bolt on subframe
Suspension - Front
Marzocchi 45 mm upside down forks, manual rebound and compression damping adjustment
Suspension - Rear
Marzocchi rear suspension unit, electronically adjustable preload and rebound damping
Rake
24.6°
Trail
133 mm / 5.2 in.
Wheel Travel - Front
180 mm / 7.1 in.
Wheel Travel - Rear
170 mm / 6.7 in.
Instrumentation
TFT multifunctional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and Riding Modes.
Lighting system
All LED lighting
Brakes - Front
Double disc. Floating discs, Brembo Stylema 4-piston Monobloc calipers. Radial front master cylinder, Multi-mode ABS, Optimized Cornering ABS.
Brakes - Rear
Single disc. Brembo single-piston sliding caliper, Multi-mode ABS, Optimized cornering ABS
Rims
Cast alloy
Tyres - Front
100/90-19
