Key Specifications
Engine
Four stroke, transverse four cylinder, DOHC, 5 valves per cylinder.
Power
171.3 hp / 126 kW @ 12500 rpm
Torque
107 Nm / 10.91 kg-m @ 10500 rpm
Top Speed
296.1 km/h / 184 mph
Weight
185 kg / 407.8 lbs
Fuel Capacity
18 Litres / 4.7 gal
Advertisement
Full 2005 Yamaha YZF 1000 R1 Specifications
Year
2005
Make Model
Yamaha YZF1000 R1
Seat Height
833 mm / 32.3 in
Wheelbase
1395 mm / 54.9 in
Ground Clearance
135 mm / 5.3 in
Height
1105 mm / 43.5 in
Length
1105 mm / 43.5 in
Width
720 mm / 28.3 in
Dry Weight
172 kg / 379 lbs
Fuel Capacity
18 Litres / 4.7 gal
Wet Weight
185 kg / 407.8 lbs
Displacement
998 cc / 60.9 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 5 valves per cylinder.
Bore x Stroke
77 X 53.6 mm
Compression Ratio
12.1:1
Cooling System
Liquid cooled
Engine Oil Specification
Synthetic, 10W/40
Exhaust
Alloy muffler
Fuel Consumption
17.8 km/lit
Fuel Induction
Fuel injection, dual-valve throttle bodies with motor-driven secondary valves, 45 mm throttle body
Ignition
TCI (Transistor Controlled Ignition)
Lubrication
Wet sump
Spark Plug
NGK, CR9EK
Starter
Electric
Clutch
Wet, multiple discs, cable operated
Final Drive
#530 O-ring chain
Transmission / Drive
6 Speed
Frame Type
Deltabox V aluminium aluminium, twin spar
Suspension - Front
43mm Kayaba inverted telescopic forks, preload, compression and rebound damping adjustable.
Suspension - Rear
Truss-type Aluminium swinging arm Monocross, preload, compression and rebound damping adjustable.
Rake
24°
Trail
91 mm / 3.8 in
Wheel Travel - Rear
120 mm / 4..7 in
Wheel Travel - Rear
130 mm / 5.1 in
Brakes - Front
2 x 320mm discs 4 piston calipers
Brakes - Rear
Single 220mm disc 4 piston caliper
Tyres - Front
120/70 ZR17
Tyres - Rear
190/50 ZR17
Wheels - Front
3.50-17
Wheels - Rear
6.00-17
