Key Specifications
Power
136.1 kW / 182.5 hp @ 12000rpm
Torque
117 Nm / 11.9 kg fm / 86.3 lb.ft @ 10000rpm
Top Speed
299 km/h / 185.8 mph
Fuel Capacity
17.5 Litres / 4.6 US gal / 3.8 Imp gal
Advertisement
Full 2010 Suzuki GSX-R 1000 Specifications
Year
2010
Colours
Blue/White, Black/Silver, Black/Maroon
Make Model
Suzuki GSX-R 1000
Ground Clearance (mm)
130 mm
Ground Clearance (in.)
5.1 inches
Seat Height
810 mm / 31.9 in.
Wheelbase
1405 mm / 55.3 in.
Ground Clearance
130 mm / 5.1 in.
Height
1130 mm / 44.5 in
Length
1130 mm / 44.5 in
Width
720 mm / 28.3 in
Dry Weight
220 kg / 485.0 lbs
Fuel Capacity
17.5 Litres / 4.6 US gal / 3.8 Imp gal
Wet Weight
205 kg / 452 lbs
Fuel Control
DOHC
Engine Type
V2, four-stroke
Displacement
998.6 cc / 60.9 cub. in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC
Fuel System
Injection
Bore x Stroke
74.5 x 57.3 mm
Compression Ratio
12.8:1
Cooling System
Liquid cooled
Engine Lubrication
Wet sump
Engine Oil Specification
Synthetic, 10W/40
Exhaust
4 into 2, stainless steel
Fuel Induction
Fuel Injection
Ignition
Electronic ignition Transistorized
Lubrication
Wet sump
Spark Plug
NGK, CR9EIA-9
Starter
Electric
Valve System
4
Clutch
Hydraulically-actuated multiplate wet clutch.
Final Drive
Chain, DID50VAZ, 114 links
Gear Ratios
1st 2.562 / 2nd 2.052 / 3rd 1.714 / 4th 1.500 / 5th 1.360 / 6th 1.269:1
Gearbox
6-speed
Transmission / Drive
6 Speed, constant mesh
Frame Type
Aluminium, twin spar
Suspension - Front
Inverted telescopic, coil spring, oil damped
Suspension - Rear
Link type, coil spring, oil damped
Rake
23.9°
Wheel Travel - Front
125mm / 4.9 in.
Wheel Travel - Rear
130 mm / 5.1 in.
Brakes - Front Diameter (in.)
12.2 inches
Brakes - Front Diameter (mm)
310 mm
Brakes - Rear Diameter (in.)
8.7 inches
Brakes - Rear Diameter (mm)
220 mm
Brakes - Front
2 x 310 mm Discs 4 piston caliper
Brakes - Rear
Single 220 mm disc
Tyres - Front
120/70 ZR17 M/C (58W), tubeless
Tyres - Rear
190/50 ZR17 M/C (73W), tubeless
Wheels
Cast aluminium alloy, 3 spoke
