Key Specifications
Weight
163 kg / 359.4 lbs
Fuel Capacity
17.00 litres / 4.49 gallons
Advertisement
Full 2005 Suzuki GSX-R 750 Specifications
Colours
Blue/White, Yellow/Black, Blue/Black
Ground Clearance (in.)
5.3 inches
Ground Clearance (mm)
135 mm
Seat Height
825 mm / 32.5 in.
Wheelbase
1,400 mm / 55.1 in.
Height
1,150 mm / 45.3 in.
Length
2,055 mm / 80.9 in.
Width
715 mm / 28.1 in.
Dry Weight
163 kg / 359.4 lbs
Fuel Capacity
17.00 litres / 4.49 gallons
Bore x Stroke (in,)
2.8 x 1.8 inches
Bore x Stroke (mm)
72.0 x 46.0 mm
Displacement (cc)
748.00 cc
Displacement (ci)
45.64 cubic inches
Engine Type
In-line four
Fuel Control
DOHC
Stroke
4
Fuel System
Injection
Compression Ratio
12.3:1
Starter
Electric
Final Drive
Chain
Gearbox
6-speed
Suspension - Front
Inverted telescopic, coil spring, fully adjustable spring preload, rebound and compression damping
Suspension - Rear
Link-type, gas/oil damped, fully adjustable spring preload, compression and rebound damping
Brakes - Front
Double disc
Brakes - Rear
Single disc
Tyres - Front
120/70-ZR17
Tyres - Rear
180/55-ZR17
